型号：500MTM02 1MRB150020R0712 1HDF930512X010

中文产品介绍：

　　概述 / 特点

　　500MTM02 1MRB150020R0712 1HDF930512X010是一款带有隔离数字I/O(4个输入/输出)、RS-232C、LAN接口和以太网集线器的M2M控制器。根据您的需求，可以添加我们CONPROSYS系列的可配置模块。从开发到运行的所有过程都可以在网页浏览器上完成。诸如通过I/O信息进行Web监控、I/O信息的报警处理以及任务分支等功能，使您能够以低成本和短时间内创建云系统。此外，CPS-MCS341-DS1-131和CPS-MGS341-DS1-131内含OPC UA服务器功能。它可以与支持OPC UA客户端的各种制造商的HMI和SCADA软件直接通信。

　　CPS-MGS341-DS1-131 是数据采集器 [PLC 用 M2M gateway]，支持各种 PLC 以及各种 Modbus 设备。在有 PLC 控制的设施中，数据可以通过 PLC 用 M2M gateway 采集;在没有 PLC 控制的设施中，数据可以通过 M2M 采集器采集。

　　“PLC 用 M2M gateway” 可以同时连接最多 10 个不同制造商的以太网/计算链接。通过 CONPROSYS 系列，可以从各种类型的设施中采集数据，并进行集中管理。从开发到运行的所有过程都可以在网页浏览器上完成。I/O 信息的网页监控、I/O 信息的报警处理、任务分支等功能使您能够以低成本和短时间内创建云系统。

　　500MTM02 1MRB150020R0712 1HDF930512X010 网页监控和网页任务脚本

　　该产品包含一个Web服务器(Java小程序)。即使您的PC位于远程位置，您也可以通过Web浏览器监控和更新I/O信息。在监控屏幕上，您可以自由布局标准GUI部件(图形、滑块、按钮等)。包括监控布局、与I/O信息建立关系的所有操作都可以通过Web浏览器完成。 通过组合诸如算术运算、条件分支、数据输出等图标，您可以像在流程图中绘制它们一样设置执行或其过程。所有操作都可以在Web浏览器上完成。

　　多供应商兼容。兼容来自不同公司的PLC和Modbus设备。

　　多供应商兼容。兼容来自不同公司的PLC和Modbus设备。

　　添加堆栈类型模块

　　该产品允许用户添加各种堆叠类型模块以满足其需求。

　　*请确保添加的堆叠类型模块数量不超过16个，并且总电流消耗不超过3.3A。

　　500MTM02 1MRB150020R0712 1HDF930512X010 消息通信功能

　　使用RS-232C或以太网设备(TCP/UDP)，可以设置最多10个链接来发送或接收消息。消息通信可以通过Web任务脚本完成。

　　简单的路由器功能

　　配备简单的路由功能。可以使用DHCP服务器、静态路由、端口路由和IP路由。

英文产品介绍：

Overview/Features

500MTM02 1MRB150020R0712 1HDF930512X010 is an M2M controller with isolated digital I/O (4 inputs/outputs), RS-232C, LAN interface, and Ethernet hub. According to your requirements, we can add configurable modules from our CONPROSYS series. All processes from development to operation can be completed on a web browser. Features such as web monitoring through I/O information, alarm processing of I/O information, and task branching enable you to create cloud systems at low cost and in a short period of time. In addition, CPS-MCS341-DS1-131 and CPS-MGS341-DS1-131 contain OPC UA server functionality. It can directly communicate with HMI and SCADA software from various manufacturers that support OPC UA clients.

CPS-MGS341-DS1-131 is a data collector [PLC M2M gateway] that supports various PLCs and Modbus devices. In facilities with PLC control, data can be collected through the PLC using an M2M gateway; In facilities without PLC control, data can be collected through M2M collectors.

The 'M2M gateway for PLC' can simultaneously connect up to 10 Ethernet/computing links from different manufacturers. Through the CONPROSYS series, data can be collected from various types of facilities and centrally managed. All processes from development to operation can be completed on a web browser. The web monitoring of I/O information, alarm processing of I/O information, task branching, and other functions enable you to create cloud systems at low cost and in a short period of time.

500MTM02 1MRB150020R0712 1HDF930512X010 Web Monitoring and Web Task Script

This product includes a web server (Java mini program). Even if your PC is located remotely, you can monitor and update I/O information through a web browser. On the monitoring screen, you can freely layout standard GUI components (graphics, sliders, buttons, etc.). All operations, including monitoring layout and establishing relationships with I/O information, can be completed through a web browser. By combining icons such as arithmetic operations, conditional branches, data output, etc., you can set the execution or its process as if drawing them in a flowchart. All operations can be completed on a web browser.

Multi vendor compatibility. Compatible with PLCs and Modbus devices from different companies.

Multi vendor compatibility. Compatible with PLCs and Modbus devices from different companies.

Add stack type module

This product allows users to add various stacking types of modules to meet their needs.

*Please ensure that the number of stacked modules added does not exceed 16 and the total current consumption does not exceed 3.3A.

500MTM02 1MRB150020R0712 1HDF930512X010 message communication function

Using RS-232C or Ethernet devices (TCP/UDP), up to 10 links can be set up to send or receive messages. Message communication can be completed through web task scripts.

Simple router functionality

Equipped with simple routing function. DHCP servers, static routing, port routing, and IP routing can be used.
